Product Details
TTO heat transfer printing and coding machine
Classification:
Product Description
Key words:
Product Introduction
Functional Characteristics
Boost your brand: With a 300DPI printing effect, enhance the appearance level of your products, and make your corporate brand stand out among peers.
Blessing your benefits: Can print real-time dates, times, and batch numbers; Accessible switching of printed content; The longest color band is 650 meters, reducing the frequency of changing bands; Humanized human-machine interface and simple operation mode; The editing software is intuitive and easy to learn. Optimize your production line control and reduce costs.
Boosting your competitive advantage: Equipped with variable digital, barcode, and QR code printing functions. Can achieve product traceability, anti-counterfeiting, and anti-counterfeiting management. Enhance your overall corporate image and competitive advantage.
Protect your product: The packaging film is not damaged. Extend the shelf life; Clear identification to avoid premature delisting.
Protect your property: Use two sizes of print head widths, 32mm and 53mm, and different width specifications such as 22.25.33.35.55mm ribbon. Meet various coding requirements through reasonable configuration; The gap between ribbon printing is only 0.5mm; High definition and high adhesion coding effect to avoid complaints. Comprehensively reduce various direct and indirect costs.
Protect your channel: Print variable barcodes, QR codes, and achieve product traceability through a full circulation software system. Prevent counterfeit and counterfeit goods, and provide support for sales channels.
Protecting Your Safety: The protective design of the ribbon box and the high cleanliness characteristics of the ribbon. Ensuring production and product safety. It also profoundly affects the safety of enterprises.
Protecting Our Environment: Design for Energy Conservation, Low Consumption, and Emission Reduction. Make due contributions to environmental improvement.
Parameter Configuration
| R320 intermittent mode, R320 continuous mode | R530 intermittent mode, R530 continuous mode | |||
| Print Head | 32mm wide, 300dpi (12 dots/mm) | 53mm wide, 300dpi (12 dots/mm) | ||
| Printing Range | 32mm×60mm 32mm×100mm | 53mm×80mm 53mm×150mm | ||
| Printing Speed | Up to 40 meters per minute | Up to 32 meters per minute | ||
| Printing Frequency | Up to 450 times per minute, Up to 300 times per minute | Up to 450 times per minute, Up to 300 times per minute | ||
| Band Length | 500 | |||
| Band Width | 22mm~33mm | 35mm~55mm | ||
| Communication Interface | USB, RS232 communication | |||
| Supply Voltage | 110-220V 50/60Hz | |||
| Power | 200W | 300W | ||
| Working Environment Temperature | 0~40℃ | |||
| Relative Humidity | 10%~95% (non condensing) | |||
| Gas Source | 6bar/90psi (maximum), dry, pollution-free | |||
| Weight | Print body: 8.5KG, control box: 2.0KG | Printed body: 9.5KG, control box: 2.0KG | ||
| Dimensions: L x W x H (Unit: mm) |
Print body: 188X190X180 |
Control box: 175X235X110 |
Print body: 210X210X185 |
Control box: 175X235X110 |
TTO heat transfer coding machine is currently one of the most cost-effective intelligent coding machines in the world, mainly suitable for various soft packaging labeling solutions such as food, pharmaceuticals, daily chemicals, seeds, household paper, financial banknotes, etc.
Weili brand-the creator of quality logo. We are committed to providing high-quality logo technology and services for manufacturers around the world. In order to meet the market demand, Weili brand has developed W700M series small character inkjet printer suitable for small and medium-sized enterprises. Its excellent stability, better than a variety of harsh working environment, high-quality printing and high utilization of consumables, effectively improve production efficiency and cost savings.
