WL-VU5500 Variable Data Spray Printing System
Classification:
Product Description
Key words:
Product Introduction
A Leader in High-quality Variable Data Printing
The WL-VU5500 Variable Data Spray Printing System can print various types of variable data such as barcodes, text, databases, serial numbers, variable images, anti-counterfeiting codes, etc. It has a wide range of applications and rich software and hardware interfaces. It can be configured on various rotary printing equipment, single paper feeding equipment, roll paper feeding equipment, and various connected and offline devices. It is an ideal supporting function expansion equipment for pre press and post press.
Product Features
◆ Simple design and powerful functionality
◆ Adopting piezoelectric spray printing technology
◆ Siphon and negative pressure ink supply systems are optional to ensure the stability of continuous printing
◆ The maximum printing height can reach 72mm
◆ Can support multi head spray printing
◆ Maximum printing speed of 120 meters per minute
◆ Can spray print various common QR codes and barcodes
◆ Supports various common fonts, making editing simple and easy to learn
| Operating Environment | |||
| Temperature | 0-50℃ | ||
| Relative temperature | 5% -90%, no condensation | ||
| Voltage | 220V, equipped with a stable power supply | ||
| Printing System | |||
| Equipment model | Pratt & Whitney 700 Series (Seiko 1020) | Pratt & Whitney 300 Series (Pratt & Whitney 512) | Pratt & Whitney 500 Series (Ricoh G5/G6) |
| Spray nozzle width | 72mm | 36mm | 54mm |
| Main application scenarios | Vertical spray, Side spray | Vertical spray, Side spray | Vertical spray |
| Maximum printing unit | 6 | 6 | 8 |
| Printing accuracy | 360dpi | 360dpi | 600dpi |
| Ink droplet size | 35PL | 30PL | 7PL、14PL |
| Max. printing speed | 60 m/min | 60 m/min | 200m/min |
| Bar level | Grade A | Grade A | Grade A |
| Ink type | Eco-friendly LED-UV Ink | ||
| Ink color | Black, white, blue, red lights, can also support special inks such as colourless fluorescent ink | ||
| Spray Printing Medium | Paper, gold and silver card, self-adhesive, metal, plastic, film, UA white ink, corrugated | ||
| Nozzle Maintenance | Automatic cleaning | ||
| Software System | |||
| What You See Is What You Get for Windows | |||
| Pratt & Whitney Typesetting System | Chinese and English characters, numbers, a bunch of barcodes, 2D barcodes, special code systems, images, nested databases, etc. | ||
| P&W Data Generation System | Generation of reverse and forward data and special versions of data formats. | ||
| P&W Data Conversion System | Software for converting various database formats, adding or subtracting data prefixes, etc. | ||
| P&W Print Management System | Professional print management software, complementary printing software, etc. | ||
Scope of Application
Can be used in cartons, plastics, glass, metal and other materials to support a variety of different colours of oil, UV ink can be sprayed sideways, downward or at a certain angle to print a variety of options.
Weili brand-the creator of quality logo. We are committed to providing high-quality logo technology and services for manufacturers around the world. In order to meet the market demand, Weili brand has developed W700M series small character inkjet printer suitable for small and medium-sized enterprises. Its excellent stability, better than a variety of harsh working environment, high-quality printing and high utilization of consumables, effectively improve production efficiency and cost savings.
